TC Electronic M2000(数字效果处理器）
详情说明
可令你创造出奇妙的效果声，皆因采用了TC ELECTRONIC DARCTM晶片技术。独特的DYNAMIC MORPHING动态渐变，可在歌声于低电平时加入和声，当进入高电平时渐渐变成加边效果。M-2000的预置混响程序中，你会找到优异的C.O.R.E.REVERBTM混响新概念。在平滑流畅，剧烈紧张，及细致感觉上，M-2000与其他混响相比，得到了很大的改进。面板上有4个快速键可储存混合效果，使用时只须一按，便可即时更改2个处理器的效果，参数及连线，极适合现场使用。
此数字效果处理器能给你了不起的混响库，变调，延时，和声，立体声扩展等多种不同效果。为你带来清晰及细致的效果，声音质量更是你从未感受过。
主要特点：
真正的双立体声"DUAL-ENGINE"双处理器结构，带6种不同内部连线选择
DYNAMIC MORPHING动态渐变及内部效果跳线交接重叠并可调节变动时间
24比特AES/EBU及24比特S/PDIF数字输入/输出
16比特数字转换工具可适用于不同的DAT数字录音机
Wizard魔术面板辅助菜单可协助用户选择预制程序
其他特点：
250个预制效果
128个用户自定义程序及128个用户混合效果自定义程序
4个快捷键可存储混合效果
敲击节拍器和MIDI节拍器和准确控制混响时间和延时时间等
可同时处理6个不同的声音变调
带有PCMCIA卡槽，用户可存储自己常用的预制
Main features
Magic
The M2000 provides you with a broad palette of high quality effects enabling you to create magical effects. The true dual engine configuration allows you to run two full-blown effects simultaneously, i.e. on two individual effects sends. The effects have been developed for optimal sonic quality with no compromises made. This has only been possible because our engineers succeeded in combining the latest technology with TC's powerful DARC™ chip.
Ultimate User-Interface
The user-friendly TC feature, the Recall Wizard, instantly finds the preset that suits your need in any situation. You simply enter your preferences, such as gentle reverb for vocal, or extra pitch for guitar and the Wizard serves you a short list of presets ready to compare and use.
Uncompromising Effects
The M2000 gives you access to a stunning array of Reverb, Pitch-shifting, Delays, Chorus, Dynamics etc. Among the included reverbs you’ll find the unique Co-efficient Optimized Room Emulator or C.O.R.E. Reverb™ based upon TC’s famous reverberation Technology.
Another unique feature in the M2000 is the Dynamic Morphing. This function enables you to apply e.g. Chorus to a vocal at low volume levels, while the same effect is being morphed into flanging at high levels giving the signal a totally new dynamic dimension.
The Sensation
The M2000 is fully prepared for the digital age with Digital I/O connectors, S/PDIF and the professional format AES/EBU. However, specifications never tell the whole story. What really matters is how your final mix sounds. This is where TC’s long experience and know-how in high-end studio signal processing becomes important.
More Features
· 250 factory presets, including Delay, Reverb, Ambience, Pitch, Dynamics, EQ + more.
· True stereo Twin Engine processing with six different routings available.
· Dynamic Morphing™ and Patch Glide with adjustable glide times.
· 24bit Analog Conversion (105dB Dynamic Range A to D): 10Hz-20Khz bandwidth
· AES/EBU (24bit) and SPDIF (24bit) digital I/O. + 16bit dithering tool for DAT output.
· Wizard Help menus assist user in preset choices on an easy to read scrolling bit-mapped display.
· Tap tempo and MIDI tempo Delay presets. Tap tempo button and footswitch jack.
· Both 128 user and 128 Combi-user presets + 4 snapshot memories.
· Universal auto-switching power supply (100-240V.)
Technical Specifications
Digital Inputs and Outputs
Connectors
XLR (AES/EBU)
RCA Phono (S/PDIF)
Optical (Tos-link, ADAT)
Formats
AES/EBU 824-bit),
S/PDIF (24 bit), EIAJ CP-340, IEC 958,
EIAJ Optical (Tos-link),
ADAT Lite pipe (24 bit)
Output Dither
HPF/TPDF dither 8-20 bit, independent dithered output
Word Clock Input
RCA Phono, 75 Ω, 0.6 to 10 Vpp
Sample Rates
32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Processing Delay
0.2 ms @ 48 kHz
Frequency Response DIO
DC to 23.9 kHz ± 0.01 dB @ 48 kHz
DC to 47.9 kHz ± 0.01 dB @ 96 kHz
Analog Inputs
Connectors
XLR balanced (pin 2 hot)
Impedance
20 KΩ
Max. Input Level
·22 dBu (balanced)
Max Input Level (for 0 dBFS)
-10 dBu
Sensitivity
· 12 dB headroom: -22 dBu to +10 dBu
A to D Conversion
24 bit (6.144 MHz delta sigman @ 48/96 kHz)
A to D Delay
0.8 ms @ 48 kHz, 0.4 ms @ 96 kHz
Dynamic Range
>103 dB (unweighted, BW = 22 kHz), >106 dB(A)
THD
-95 dB (0,0018 %) @ 1 kHz, -6 dBFS (FS @ + 16 dBu)
Frequency Response
10 Hz to 20 kHz : +0/-0.2 dB @ 48 kHz
10 Hz to 45 kHz : +0/-1 dB @ 96 kHz
Crosstalk
<-80 dB, 10Hz to 20 kHz
typical -100 dB @ 1 kHz
Analog Outputs
Connectors
XLR balanced (pin 2 hot)
Impedance
100 Ω (active transformer)
Max. Output Level
·22 dBu (balanced)
Full Scale Output Range
-10 dBu to +22 dBu
D to A Conversion
24 bit (6.144 MHz delta sigman @ 48/96 kHz)
D to A Delay
0.57 ms @ 48 kHz, 0.28 ms @ 96 kHz
THD
-82 dB (0.008 %) @ 1 kHz, -6 dBFS (FS @ + 16 dBu)
Frequency Response
10 Hz to 20 kHz : +0/-0.5 dB @ 48 kHz
10 Hz to 45 kHz : +0/-3 dB @ 96 kHz
Crosstalk
<-60 dB, 10Hz to 20 kHz
typical -90 dB @ 1 kHz
EMC
Complies with
EN 55103-1 and EN 55103-2
FCC part 15, Class B
CISPR 22, Class B
Safety
Certified to
IEC 60065, EN 60065, UL 6500 and
CSA E65
CSA File£LR108093
Enviroment
Operating Temperature
32° F to 122° F (0° C to 50° C)
Storage Temperature
-22° F to 167° F (-30° C to 70° C)
Humidity
Max. 90 % non-condensing
PCMCIA Interface
Connector
PC Card, 68 pin type 1 cards
Standards
PCMCIA 2.0, JEIDA 4.0
Card Format
Supports up to 2 MB SRAM
Control Interface
MIDI
In/Out/Thru: 5 Pin DIN
General
Finish
Anodized aluminum front
Plated and painted steel chassis
Display
56 x 128 dot graphic LCD
Dimensions
19" x 1.75" x 8.2" (483 x 44 x 208 mm)
Weight
5.2 lb. (2.35 kg)
Mains Voltage
100 to 240 VAC, 50 to 60 Hz
(auto-select)
Power Consumption
<20 W
Backup Battery Life
>10 years
Carry-in Warrenty
Parts and labor
1 year
